The Crossbow (SMA-Male) MIMO Cross Polarized 5G Antenna

Price excludes shipping, customs, VAT

We’ve got cross-performance covered.

5G capable and covers 617-3800Mhz cellular frequencies
Cross-polarization for optimal performance
Up to +11 dBi of gain with 5m w/ SMA-Male termination, SMA-Male termination
Ideal for direct connection to a MIMO cellular router, modem, or hotspot

5G/4G LTE? Check. High gain? Check. Directional? Check. This version has 5 meters of cable with SMA-Male termination. Run it to your MIMO cellular router, modem or hotspot.

mimo cross polarized antenna specifications

Download the Geek Sheet

Details
Geek Stuff

Check out the big “X” on the front of The Crossbow. That’s where it got its name. The Crossbow is our 5G/4G LTE MIMO cellular hotspot antenna, optimized for cellular networks. Specifically, the Crossbow is a Cross Polarized (XPOL), cellular band, 2×2 MIMO antenna.

There are two versions of The Crossbow available. This version includes 5 meters of Twin HDF-195 cables with SMA-Male termination, ideal for easy plugin to your modem, hotspot, or router.

If you’re looking for high- gain, an easy-install, future-proofed, and versatile, look no further than The Bolton Crossbow.

Item No.	BT151052
Frequency Bands	617-894, 1710-2700, 3400-3800 MHz
Gain (max) Port 1 & 2	9, 10, 11 dBi
VSWR Port 1 & 2	≤1.5.1 Over 90% of the Band
Feed Power Handling	20 watt
Input Impedance	50 ohm (nominal)
Polarization	Horizontal and Vertical
DC Short	Path to Ground *Dual Dipole, Cross Polarized: +45° / -45°
Connector Type	N-Female
Size	262 x 262 x 90 cm, 10.32 x 10.32 x 3.50 in
Weight, without Mounting Kit	1.55 kg, 3.40 lb
Radome Color	Brilliant White
Radome Material	UV Stable ASA
Operational Temperature	-40 to +80 oC, -40 to 176 oF
Operational Humidity	98%
Wind Survival	250 km/h, 155 mph
Weather & Waterproof	IP65
Mounting Type	Wall or Pole Mount
Coax Cable Length	5 m, 16.40 ft

You have questions. We have answers.

Can the Crossbow Be Used with a Cellular Signal Booster?

No. The Crossbow is equipped with dual-antenna outputs and is therefore incompatible with single-input cell phone signal boosters.

How Do I Point the Crossbow During Installation?

The Crossbow has a 45° cross-polarized directional beam, facing front. What you’ll need to do is locate the cell tower in your area that broadcasts your carrier’s signal. Then, point the Crossbow antenna in that direction.

What Kinds of Signal Does the Crossbow Capture? What Radio Bandwidths?

The Crossbow captures any signal between the 617-3800 MHz bandwidths. That includes all 5G/4G/LTE/3G cellular signals. This covers all African Carriers.
